X/Y/Z Travel：1500×800×800mm
Max. table load：1500Kg
Spindle Speed：15000－20000rpm
Product features:
Designed specifically for graphite processing.
Fully closed-loop control to ensure accuracy.
Fully sealed protection to protect machine tool components.
Customizable to your needs.
Processable materials:
graphite, carbon fiber, ceramics, composites, and other non-metallic materials.
| S-1500V Parameters | Value |
|---|---|
| X/Y/Z Travel | 1500×800×800mm |
| Table Dimensions | 1700×810mm |
| Max. Table Load | 1500Kg |
| Spindle Face to Worktable Height | 85—885mm |
| Positioning Accuracy | ±0.005/300mm |
| Repeatability | ±0.003/300mm |
| Tool Capacity | 24 |
| Spindle Speed | 15000－20000Rpm |
| Moving Speed | 15m-20m/min |
| Cutting Speed | 10m-20m/min |
| Tool Change Time | 2 seconds |
| Dimensions (L/W/H) | 4050×2850×3850mm |
| Weight | 10000Kg |
| Control Method | Fully closed-loop control |
